MPO/MTP Fiber Optic Fanout Cable
NEWSUN TECH
MTP/MPO HARNESS FANOUT CABLE
MPO Fanout cable assemblies are with a single 12/24 core MPO connector in one end and LC/SC connectors for another end. Directly connecting the backbone cable with the equipment without MPO cassette, beside it, the cable is also used for cable expanding in the data center.
MPO/MTP-LC 12-core, MPO/MTP Hydra cable, 0.9mm cable (standard: type A)
MPO/MTP-LC 12 core Harness cable, branch 2.0/3.0mm cable, straight (standard: type A)
Full Crossed (Type B): Method B uses crossed Type B backbones (pin1 to pin12) and MPO adapters of Type B (key-up to key-up). However, as the Type B adapters are used differently on both sides (key-up to key-up, key-down to key-down), a higher level of planning is required. An uncrossed patch cord (A-to-B) is used at both ends of the link.
Method B is not widespread, due to the higher amount of planning required and also because the method does not allow for use of single-mode MPO connectors. In addition, R&M does not support this method (or rather, only upon specific customer request).
MTP/MPO HARNESS FANOUT CABLE
MPO Fanout cable assemblies are with a single 12/24 core MPO connector in one end and LC/SC connectors for another end. Directly connecting the backbone cable with the equipment without MPO cassette, beside it, the cable is also used for cable expanding in the data center.
MPO/MTP-LC 12-core, MPO/MTP Hydra cable, 0.9mm cable (standard: type A)
MPO/MTP-LC 12 core Harness cable, branch 2.0/3.0mm cable, straight (standard: type A)
Full Crossed (Type B): Method B uses crossed Type B backbones (pin1 to pin12) and MPO adapters of Type B (key-up to key-up). However, as the Type B adapters are used differently on both sides (key-up to key-up, key-down to key-down), a higher level of planning is required. An uncrossed patch cord (A-to-B) is used at both ends of the link.
Method B is not widespread, due to the higher amount of planning required and also because the method does not allow for use of single-mode MPO connectors. In addition, R&M does not support this method (or rather, only upon specific customer request).
MPO/MTP Fiber Optic Fanout Cable
12 to 144 core cable connection
Adopts 4, 8, 12 or 24 core MPO connector. Reduce fault failure rate and save space
Smoothly upgrade 10G network to 40G, 100G network, support 100G transmission latency requirement
Optional multimode OM3, OM4, single mode G 652D, G 657A2 fiber requirement
Adopts mini round type cable, small diameter, with smaller trunk cable and smaller bending radius, easy for storage and cable install
Use dustproof, compressive strength, tensile strength protective sleeve at both ends, can effectively protect cables and fiber optic connectors in the transportation and installation process from damage
Customized, high adaptability
Optional different fiber cores and cable structure for different installation requirement
PVC, LSZH, OFNR, OFNP cable jacket available
Improved and simplified cabling, reduce cabling spacing
All patch cable are 100% tested, test report supplied with each cable assembly
Tests Interferometer, Insertion Loss, Return Loss and Visual Final Inspection; all measured values are electronically archived
Applications
Data Center
Fiber to the home
High density fiber optic cable management
40Gb/s or 100Gb/s Applications
Standards Compliance
TIA/EIA-568-C
IEC-61754-7
NFPA 262 (OFNP) or IEC 60332 (LSZH)
IEC-60793
GR-1435-CORE
MPO/MTP Fiber Optic Fanout Cable
12 to 144 core cable connection
Adopts 4, 8, 12 or 24 core MPO connector. Reduce fault failure rate and save space
Smoothly upgrade 10G network to 40G, 100G network, support 100G transmission latency requirement
Optional multimode OM3, OM4, single mode G 652D, G 657A2 fiber requirement
Adopts mini round type cable, small diameter, with smaller trunk cable and smaller bending radius, easy for storage and cable install
Use dustproof, compressive strength, tensile strength protective sleeve at both ends, can effectively protect cables and fiber optic connectors in the transportation and installation process from damage
Customized, high adaptability
Optional different fiber cores and cable structure for different installation requirement
PVC, LSZH, OFNR, OFNP cable jacket available
Improved and simplified cabling, reduce cabling spacing
All patch cable are 100% tested, test report supplied with each cable assembly
Tests Interferometer, Insertion Loss, Return Loss and Visual Final Inspection; all measured values are electronically archived
Applications
Data Center
Fiber to the home
High density fiber optic cable management
40Gb/s or 100Gb/s Applications
Standards Compliance
TIA/EIA-568-C
IEC-61754-7
NFPA 262 (OFNP) or IEC 60332 (LSZH)
IEC-60793
GR-1435-CORE
MTP (Mechanical Transfer Push-on) connector structure is an improved version of MPO (Multi-fiber push-on) connector. The MTP connector has elliptical guide pins of noncorrosive steel for accurate location of fibers of the two commutating connectors and reduction of wear. Also the MT-ferrule has a floating structure that provides integrity of physical contact of the connectors under load.
Difference between MPO Connector and MTP Connector
From the outside there is very little noticeable difference between MPO and MTP connectors. In fact, they are completely compatible and inter-mateable. For example, an MTP trunk cable can plug into an MPO outlet and vice versa.
The main difference is in relation to its optical and mechanical performance. MTP is a registered trademark and design of US Connec, and provides some advantages over a generic MPO connector. Since MPO / MTP optic fiber alignment is critical to ensure a precise connection there are some benefits in utilizing the MTP connector. The MTP connector is a high performance MPO connector with multiple engineered product enhancements to improve optical and mechanical performance when compared to generic MPO connectors.
The MTP optic fiber connector has floating internal ferrule which allows two mated ferrules to maintain contact while under load. In addition, The MTP connector spring design maximizes ribbon clearance for twelve fiber and multifiber ribbon applications to prevent fiber damage.
Overall it provides a more reliable and precise connection. In addition, it is also important when specifying an MPO/MTP system to ensure the correct polarity options and which cables and outlets have female or male pins.
MTP (Mechanical Transfer Push-on) connector structure is an improved version of MPO (Multi-fiber push-on) connector. The MTP connector has elliptical guide pins of noncorrosive steel for accurate location of fibers of the two commutating connectors and reduction of wear. Also the MT-ferrule has a floating structure that provides integrity of physical contact of the connectors under load.
Difference between MPO Connector and MTP Connector
From the outside there is very little noticeable difference between MPO and MTP connectors. In fact, they are completely compatible and inter-mateable. For example, an MTP trunk cable can plug into an MPO outlet and vice versa.
The main difference is in relation to its optical and mechanical performance. MTP is a registered trademark and design of US Connec, and provides some advantages over a generic MPO connector. Since MPO / MTP optic fiber alignment is critical to ensure a precise connection there are some benefits in utilizing the MTP connector. The MTP connector is a high performance MPO connector with multiple engineered product enhancements to improve optical and mechanical performance when compared to generic MPO connectors.
The MTP optic fiber connector has floating internal ferrule which allows two mated ferrules to maintain contact while under load. In addition, The MTP connector spring design maximizes ribbon clearance for twelve fiber and multifiber ribbon applications to prevent fiber damage.
Overall it provides a more reliable and precise connection. In addition, it is also important when specifying an MPO/MTP system to ensure the correct polarity options and which cables and outlets have female or male pins.
