Self-supporting Bow-type Fiber Optic Drop Cable
NEWSUN
08
Dual FRP Reinforcement: Two parallel Fiber Reinforced Polymer (FRP) strength members provide outstanding crush resistance to safeguard the optical fibers.
Enhanced Tensile Strength: Incorporates a single steel wire with supplementary reinforcement, offering superior tensile performance for aerial installations.
Streamlined Construction: The design prioritizes simplicity, ensuring high functionality and practical ease of use.
Innovative Flute Design: Features a uniquely grooved sheath for effortless stripping and splicing, which streamlines both installation and future maintenance.
Safety-Oriented Sheath: Utilizes a low-smoke, zero-halogen (LSZH), and flame-retardant outer jacket, prioritizing operational safety and environmental protection.
1. LSZH Jacket
2. FRP Strength Member
3. Optical Fibre Unit
4. Steel Wire
Dual FRP Reinforcement: Two parallel Fiber Reinforced Polymer (FRP) strength members provide outstanding crush resistance to safeguard the optical fibers.
Enhanced Tensile Strength: Incorporates a single steel wire with supplementary reinforcement, offering superior tensile performance for aerial installations.
Streamlined Construction: The design prioritizes simplicity, ensuring high functionality and practical ease of use.
Innovative Flute Design: Features a uniquely grooved sheath for effortless stripping and splicing, which streamlines both installation and future maintenance.
Safety-Oriented Sheath: Utilizes a low-smoke, zero-halogen (LSZH), and flame-retardant outer jacket, prioritizing operational safety and environmental protection.
1. LSZH Jacket
2. FRP Strength Member
3. Optical Fibre Unit
4. Steel Wire
Cable Model | Fibre Count | Cable Size （mm） | Cable Weight (Ref) （kg/km） | Tensile Strength Long/Short Term （N) | Crush Resistance Long/Short Term (N/100mm) | Bending Radius Dynamic/Static (mm) |
GJYXFCH-1Xn | 1 | (2.0±0.1)*(5.0±0.1) | 20 | 300/600 | 1000/2200 | 15/30 |
GJYXFCH-2Xn | 2 | (2.0±0.1)*(5.0±0.1) | 20 | 300/600 | 1000/2200 | 15/30 |
GJYXFCJH-1Xn | 1 | (2.0±0.1)*(5.6±0.1) | 21 | 300/600 | 1000/2200 | 15/30 |
GJYXFCDH-4Xn | 4(Ribbon) | (2.0±0.2)*(6.0±0.2) | 22 | 300/600 | 1000/2200 | 15/30 |
Storage/Operating Temperature: -20℃~+60℃
Fiber Type | Attenuation | OFL | Effective Mode Bandwidth | 10 Gbit/s Ethernet Link Length | Minimum Bend Radius | |||
Condition | 1310/1550nm | 850/1300nm | 850/1300nm | 850nm | 850nm | / | ||
Typical Value | Maximum Value | Typical Value | Maximum Value | |||||
Unit | dB/km | dB/km | dB/km | dB/km | MHZ.km | MHZ.km | m | mm |
G657A1 | 0.36/0.22 | 0.5/0.4 | --- | --- | --- | --- | --- | 10 |
G657A2 | 0.36/0.22 | 0.5/0.4 | --- | --- | --- | --- | --- | 7.5 |
OM3 | --- | --- | 3.0/1.0 | 3.5/1.5 | ≥1500/500 | ≥2000 | ≤300 | 30 |
OM4 | --- | --- | 3.0/1.0 | 3.5/1.5 | ≥3500/500 | ≥4700 | ≤550 | 30 |
Cable Model | Fibre Count | Cable Size （mm） | Cable Weight (Ref) （kg/km） | Tensile Strength Long/Short Term （N) | Crush Resistance Long/Short Term (N/100mm) | Bending Radius Dynamic/Static (mm) |
GJYXFCH-1Xn | 1 | (2.0±0.1)*(5.0±0.1) | 20 | 300/600 | 1000/2200 | 15/30 |
GJYXFCH-2Xn | 2 | (2.0±0.1)*(5.0±0.1) | 20 | 300/600 | 1000/2200 | 15/30 |
GJYXFCJH-1Xn | 1 | (2.0±0.1)*(5.6±0.1) | 21 | 300/600 | 1000/2200 | 15/30 |
GJYXFCDH-4Xn | 4(Ribbon) | (2.0±0.2)*(6.0±0.2) | 22 | 300/600 | 1000/2200 | 15/30 |
Storage/Operating Temperature: -20℃~+60℃
Fiber Type | Attenuation | OFL | Effective Mode Bandwidth | 10 Gbit/s Ethernet Link Length | Minimum Bend Radius | |||
Condition | 1310/1550nm | 850/1300nm | 850/1300nm | 850nm | 850nm | / | ||
Typical Value | Maximum Value | Typical Value | Maximum Value | |||||
Unit | dB/km | dB/km | dB/km | dB/km | MHZ.km | MHZ.km | m | mm |
G657A1 | 0.36/0.22 | 0.5/0.4 | --- | --- | --- | --- | --- | 10 |
G657A2 | 0.36/0.22 | 0.5/0.4 | --- | --- | --- | --- | --- | 7.5 |
OM3 | --- | --- | 3.0/1.0 | 3.5/1.5 | ≥1500/500 | ≥2000 | ≤300 | 30 |
OM4 | --- | --- | 3.0/1.0 | 3.5/1.5 | ≥3500/500 | ≥4700 | ≤550 | 30 |
