Bow-type Fiber Optic Drop Cable
NEWSUN
08
FTTH drop cable, also known as butterfly or indoor drop cable, is specifically designed for the final segment of fiber-to-the-home (FTTH) networks. Its structure typically features a central fiber unit reinforced by two parallel strengthening elements (such as metal wire, non-metallic FRP, or KFRP), with an additional outer steel wire hanger, all encased in a low-smoke, zero-halogen (LSZH) sheath. This design ensures robustness while maintaining a lightweight profile. The cable usually contains a small number of fiber cores, typically ranging from 1 to 4, but can be increased up to 12 cores to meet higher demand. This makes it well-suited for short-distance transmission and indoor cabling applications. The cable is highly flexible and lightweight, facilitating installation in tight bends and confined spaces, which is particularly advantageous in residential and office environments. It exhibits excellent tensile and lateral pressure resistance, with the strengthening elements ensuring stability and reliability during installation. Constructed from flame-retardant, low-smoke, zero-halogen materials, it offers enhanced safety by minimizing smoke and toxic gas emissions in the event of a fire, protecting both personnel and property. As a critical component of FTTH networks, it forms the link between the user access point and the terminal, delivering high-speed, stable internet connectivity. Beyond FTTH, it is also widely used in other fiber access networks like fiber-to-the-office (FTTO) and fiber-to-the-building (FTTB), as well as in indoor cabling for homes, offices, and data centers, where its flexibility, lightweight, strength, and pressure resistance make it an ideal choice.
Bend-Optimized Fiber: Utilizes specialized low-bend-sensitivity fiber that maintains signal integrity in tight spaces while enabling exceptional bandwidth for data transmission.
Reinforcement Structure: Incorporates dual parallel FRP or steel reinforcement elements to provide robust resistance against pressure while protecting the internal fiber components.
Structural Efficiency: Adopts a streamlined bow-type design that eliminates complex layering, offering a balance of mechanical durability and functional adaptability.
Streamlined Flute Design: Features an innovative grooved sheath configuration that enables rapid stripping and splicing, significantly reducing deployment time and maintenance complexity.
Safety & Compliance:
Fire-Resistant Sheathing: Constructed with low-smoke, zero-halogen (LSZH) materials that suppress flame propagation and minimize toxic emissions in enclosed environments.
Applications:
FTTH Deployments: Optimally engineered for "last-mile" connectivity in fiber-to-the-home installations, ensuring reliable signal delivery to end-user premises.
High-Density Environments: Ideal for structured cabling in multi-dwelling units and commercial buildings where space constraints demand compact, flexible solutions.
Rapid Deployment Scenarios: Engineered for projects requiring quick termination and minimal downtime, such as temporary network expansions or emergency restorations.
1.LSZH Jacket
2.FRP Strength Member
3.Optical Fibre Unit
