Mobile Fiber Optic Cable MOC
NEWSUN
21
Mobile optical cable is a communication solution that utilizes optical transmission technology to connect data centers, communication base stations, and internet access equipment. It enables high-speed transmission of voice, data, and video information.
The operation of mobile optical cables relies on the principle of light total internal reflection. When light enters the optical fiber at a specific angle, it undergoes complete reflection at the boundary between the core and cladding materials, allowing it to propagate through the fiber with minimal loss. During transmission, the optical signal travels through the fiber to the receiving end, where it is converted back into electrical signals for processing.
Applications:
FTTH indoor vertical wiring
Building trunk wiring optical cable
Features:
Smart structure for easy branching and extraction
Compact and lightweight for simple installation
LSZH sheath for excellent flame retardancy
Precision engineering ensures reliable mechanical and temperature performance
Optimized for cutting, extraction, and skylight applications
Mobile optical cable is a communication solution that utilizes optical transmission technology to connect data centers, communication base stations, and internet access equipment. It enables high-speed transmission of voice, data, and video information.
The operation of mobile optical cables relies on the principle of light total internal reflection. When light enters the optical fiber at a specific angle, it undergoes complete reflection at the boundary between the core and cladding materials, allowing it to propagate through the fiber with minimal loss. During transmission, the optical signal travels through the fiber to the receiving end, where it is converted back into electrical signals for processing.
Applications:
FTTH indoor vertical wiring
Building trunk wiring optical cable
Features:
Smart structure for easy branching and extraction
Compact and lightweight for simple installation
LSZH sheath for excellent flame retardancy
Precision engineering ensures reliable mechanical and temperature performance
Optimized for cutting, extraction, and skylight applications
| Cable Type | Cable Diameter | Cable Weight | Tensile Strength Long/Short term | Crush Resistance Long/Short | Bending Radius Dynamic/Static | Storage temperature |
| (mm) | (kg/km) | (N) | (N) | (mm) | (℃) | |
| GJPFWQH-24 (4cx6s) | 6.5±0.2 | 40 | 200/500 | 200/1000 | 20D/10D | -20°C ~ +60 |
| GJPFWQH-48 (4cx12s) | 8.5±0.2 | 60 | 200/500 | 200/1000 | 20D/10D | -20°C ~ +60 |
| GJPFWQH-96 (8cx12s) | 10.5±0.2 | 90 | 200/500 | 200/1000 | 20D/10D | -20°C ~ +60 |
| GJPFWQH-144 | 10.5±0.2 | 90 | 300/500 | 200/1000 | 20D/10D | -20°C ~ +60 |
| GJPFWQH-144 | 13.5±0.2 | 145 | 300/500 | 200/1000 | 20D/10D | -20°C ~ +60 |
Note: Transport/storage temperature: -20°C ~ +60°C
Standard length: 2000m; other lengths are also available.
Fiber type: G652D, G657A1, G657A2, 50/125, 62.5/125, OM3, OM4, OM5
| Cable Type | Cable Diameter | Cable Weight | Tensile Strength Long/Short term | Crush Resistance Long/Short | Bending Radius Dynamic/Static | Storage temperature |
| (mm) | (kg/km) | (N) | (N) | (mm) | (℃) | |
| GJPFWQH-24 (4cx6s) | 6.5±0.2 | 40 | 200/500 | 200/1000 | 20D/10D | -20°C ~ +60 |
| GJPFWQH-48 (4cx12s) | 8.5±0.2 | 60 | 200/500 | 200/1000 | 20D/10D | -20°C ~ +60 |
| GJPFWQH-96 (8cx12s) | 10.5±0.2 | 90 | 200/500 | 200/1000 | 20D/10D | -20°C ~ +60 |
| GJPFWQH-144 | 10.5±0.2 | 90 | 300/500 | 200/1000 | 20D/10D | -20°C ~ +60 |
| GJPFWQH-144 | 13.5±0.2 | 145 | 300/500 | 200/1000 | 20D/10D | -20°C ~ +60 |
Note: Transport/storage temperature: -20°C ~ +60°C
Standard length: 2000m; other lengths are also available.
Fiber type: G652D, G657A1, G657A2, 50/125, 62.5/125, OM3, OM4, OM5
